Textile Image Analysis Software

Image Pickup Device

Aptina MT9P001 CMOS(Color)

Scan Mode

Progressive

Max. Resolution

2592 x 1944 (Approx.5,040,000 Pixels)

Sensor Size (Diagonal)

1/2.5" (5.70mm(H) x 4.28mm(V), Diagonal 7.13mm)

Pixel Size

2.2m x 2.2m

G Sensitivity

0.53v/lux-sec(550nm)

Dynamic Range

66.5dB

A/D Converter

12-bit Parallel, 8-bit R.G.B to PC

SN Ratio

40.5dB

Spectral Range

380-650nm (with IR-filter)

Video Format & Frame Rate

5fps @2592 x 1944, 18fps @1280 x 960, 60fps @640 x 480

Binning

1 x 1, 2 x 2, 4 x 4

Exposure

0.21~2000ms, ROI Auto & Manual

White balance

ROI White Balance/ Manual Temp-Tint Adjustment

Color Rendering Technique

Ultra Fine Color Engine

Peak Quantum Efficiency

NA

Readout Noise

N/A

Extinction Ratio

N/A

Smear

N/A

Capture/Control API

Native C/C++, C#, Direct show, Twain, Lab view

Recording System

Still Picture and Movie

Cooling System*

Natural

Operating Temperature

-10~ 50

Storage Temperature

-20~ 60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB Port

Operating System

Support Microsoft Windows XP / Vista / 7 /8 (32 & 64 bit)
OS X (Mac OS X), Linux

CPU: Equal to Intel Core2 2.8GHz or Higher

Memory: 2GB or More

USB port: USB2.0 High-speed Port

PC Requirements

Display: 17" or Larger

CD-ROM
